Fluxgate Current sensors

Product No	Primary nominal RMS current(A)	Measuring range(A)	Supply voltage (V)	Secondary output	Accuracy(%)	Output bandwidth(kHz)	Operating Temp.(°C)	Copper busbar(mm)	Others
FR1C 300 H2352A	300	±400	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H2352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H1152A	300	±400	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H1152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H1252A	300	±400	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H1252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H1352A	300	±400	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H1352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H1352B	300	±400	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H1352B Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H2152A	300	±400	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H2152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H2252A	300	±400	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H2252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 300 H2322C	300	±400	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 300 H2322C Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 250 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H1152A	500	±530	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H1152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H1252A	500	±600	12	CAN	±0.3~0.5		-40~85	Φ24.4mm	TE 1473672-1
FR1C 500 H1252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H1352A	500	±530	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H1352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H1352B	500	±530	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H1352B Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H2152A	500	±530	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H2152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H2252A	500	±530	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H2252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H2322C	500	±530	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H2322C Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 250 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 500 H2352A	500	±530	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 500 H2352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H1152A	700	±760	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H1152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H1252A	700	±760	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H1252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H1352A	700	±760	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H1352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H1352B	700	±760	12	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H1352B Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +12V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H2152A	700	±760	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H2152A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H2252A	700	±760	24	CAN	±0.3~0.5		-40~85	Φ24.4mm	TE 1473672-1
FR1C 700 H2252A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H2322C	700	±760	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H2322C Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 250 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR1C 700 H2352A	700	±760	24	CAN	±0.3~0.5		-40~85	Φ24.4 mm	TE 1473672-1
FR1C 700 H2352A Current sensor using Fluxgate technology for automotive use，BMS, SOC, SOH, SOF. Overcurrent detection mechanism Panel mounting Unipolar +24V battery power supply Output signal: High speed CAN (up to 500 kBps) Configurable internal digital low-pass frequency filter Configurable CAN speed/CAN ID UL508 compliant Ingress Protection - IP42 level. more... Products Data Sheet
FR2V 0.01 H00	0.01	±0.015	±12...15	±5V	+1.0	DC	-10~70	Ø20.0	JK2EDG-5.08-4P
FR2V 0.01 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL 94-V0.（Black） High linearity Very low zero temperature drift Standards:IEC 60664-1:2020, IEC 61800-5-1:2022, IEC 62109-1:2010 Good quality fluxgate current sensor more... Products Data Sheet
FR2V 0.02 H00	0.02	±0.03	±12...15	±5V	±1.0	DC	-10~70	Ø20	JK2EDG-5.08-4P
FR2V 0.02 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL 94-V0.（Black） High linearity Very low zero temperature drift Standards:IEC 60664-1:2020, IEC 61800-5-1:2022, IEC 62109-1:2010 DC leakage current sensor designed for electrical safety protection panel mount more... Products Data Sheet
FR2V 0.05 H00	0.05	±0.075	±12...15	±5V	±1.0	DC	-10~70	Ø20.0	JK2EDG-5.08-4P
FR2V 0.05 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL 94-V0.（Black） High linearity Very low zero temperature drift Standards:IEC 60664-1:2020, IEC 61800-5-1:2022, IEC 62109-1:2010 DC leakage current sensor for PV leakage current measurement more... Products Data Sheet
FR2V 0.1 H00	0.1	±0.15	±12...15	±5V	±1.0	DC	-10~70	Ø20.0	JK2EDG-5.08-4P
FR2V 0.1 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL 94-V0.（Black） High linearity Very low zero temperature drift Standards:IEC 60664-1:2020, IEC 61800-5-1:2022, IEC 62109-1:2010 AC and DC leakage current detection current sensor more... Products Data Sheet
FR2V 0.3 H00	0.3	±0.36	±12...15	±5V	±1.0	DC	-10~70	Ø20.0	JK2EDG-5.08-4P
FR2V 0.3 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL 94-V0.（Black） High linearity Very low zero temperature drift Standards:IEC 60664-1:2020, IEC 61800-5-1:2022, IEC 62109-1:2010 Leakage current sensor for AI data center power supply and HPC systems more... Products Data Sheet
FR5V 0.01 H00	0.01	±0.015	±12...15	±5V	±1.0	DC	-10~70	Ø40.5	JK2EDG-5.08-4P
FR5V 0.01 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL94-V0（Black） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 High measurement accuracy DC leakage current sensor more... Products Data Sheet
FR5V 0.02 H00	0.02	±0.03	±12...15	±5V	±1.0	DC	-10~70	Ø40.5	JK2EDG-5.08-4P
FR5V 0.02 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL94-V0（Black） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 High-Accuracy portable fluxgate technology leakage current sensor more... Products Data Sheet
FR5V 0.05 H00	0.05	±0.075	±12...15	±5V	±1.0	DC	-10~70	Ø40.5	JK2EDG-5.08-4P
FR5V 0.05 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL94-V0（Black） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 Good quality fluxgate current sensor more... Products Data Sheet
FR5V 0.1 H00	0.1	±0.15	±12...15	±5V	±1.0	DC	-10~70	Ø40.5	JK2EDG-5.08-4P
FR5V 0.1 H00 Current sensor based on fluxgate technology Output Voltage Insulating plastic case recognized according to UL94-V0（Black） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 Leakage current sensor for industrial automation more... Products Data Sheet
FR7V 0.005 H00	0.005	±0.007	±15	±5V	±1.0	DC	-10~70	Ø12	KF2EDG 3.81MM 4P
FR7V 0.005 H00 Current sensor based on fluxgate technology Output voltage Insulating plastic case recognized according to UL 94-V0（Blue） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 Current sensor fluxgate technology for residual current measurement more... Products Data Sheet
FR7V 0.01 H00	0.01	±0.017	±15	±5V	±1.0	DC	-10~70	Ø12	KF2EDG 3.81MM 4P
FR7V 0.01 H00 Current sensor based on fluxgate technology Output voltage Insulating plastic case recognized according to UL 94-V0（Blue） High linearity Very low zero temperature drift Standards:EN50178: 1997, IEC 61010-1: 2000, UL 508: 2010 Very low offset drift over temperature photovoltaic inverter (no transformer type) leakage current measurement current transducer more... Products Data Sheet
