开环霍尔效应电流传感器通过电隔离测量直流、交流和复杂的电流波形。其优点包括成本低、体积小、重量轻和功耗低，在测量大电流时尤其有利。
| Product No | Primary nominal RMS current(A) | Measuring range(A) | Supply voltage (V) | Secondary output | Accuracy(%) | Output bandwidth(kHz) | Operating Temp.(°C) | Copper busbar(mm) | PCB | Others |
|---|---|---|---|---|---|---|---|---|---|---|
| AN1V 100 PB311 | 100 | ±100 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~150 | NA | + | |
| AN1V 100 PB312 | 100 | ±100 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~150 | NA | + | |
| AN1V 100 PB501 | 100 | 100 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 100 PB501
|
||||||||||
| AN1V 100 PB502 | 100 | 100 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~150 | NA | + | |
| AN1V 100 PB511 | 100 | ±100 | 5 | 2.5±2V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 100 PB511
|
||||||||||
| AN1V 100 PB512 | 100 | ±100 | 5 | 2.5±2V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 100 PB512
|
||||||||||
| AN1V 150 PB311 | 150 | ±150 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 150 PB312 | 150 | ±150 | 3.3 | 1.65+1.32V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 150 PB501 | 150 | 150 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 150 PB502 | 150 | 150 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 150 PB511 | 150 | ±150 | 5 | 2.5±2V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 150 PB512 | 150 | ±150 | 5 | 2.5±2V | ±1.0 | 250 | -40~125 | NA | + | |
| AN1V 200 PB311 | 200 | ±200 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 200 PB312 | 200 | ±200 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 200 PB501 | 200 | 200 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 200 PB502 | 200 | 0-200 | 5 | 0.55+4V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 200 PB511 | 200 | ±200 | 5 | 2.5±2V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 200 PB512 | 200 | ±200 | 5 | 2.5±2V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 300 PB501 | 300 | ±300 | 5 | 0.55-4.55V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 300 PB502 | 300 | ±300 | 5 | 0.55-4.55V | ±1.0 | 250 | -40~85 | NA | + | |
| AN1V 50 PB311 | 50 | ±50 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB311
|
||||||||||
| AN1V 50 PB312 | 50 | ±50 | 3.3 | 1.65±1.32V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB312
|
||||||||||
| AN1V 50 PB501 | 50 | 50 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB501
|
||||||||||
| AN1V 50 PB502 | 50 | 50 | 5 | 0.55...4.55V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB502
|
||||||||||
| AN1V 50 PB511 | 50 | ±50 | 5 | 2.5±2V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB511
|
||||||||||
| AN1V 50 PB512 | 50 | ±50 | 5 | 2.5±2V | ±1.0 | 250 | -40~150 | NA | + | |
 AN1V 50 PB512
|
||||||||||
| AN3V 10 PB30 | 10 | ±25 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 10 PB31 | 10 | ±25 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 10 PB50 | 10 | ±25 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
 AN3V 10 PB50
|
||||||||||
| AN3V 10 PB51 | 10 | ±25 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 100 PB31 | 100 | ±250 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 100 PB35 | 100 | ±250 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 100 PB51 | 100 | ±250 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 100 PB55 | 100 | ±250 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 120 PB31 | 120 | ±300 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 120 PB35 | 120 | ±300 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 120 PB51 | 120 | ±300 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 120 PB55 | 120 | ±300 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 150 PB35 | 150 | ±375 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 150 PB55 | 150 | ±375 | 5 | 2.5±2V | +1.0 | 250 | -40~105 | NA | + | |
| AN3V 16 PB30 | 16 | ±40 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 16 PB31 | 16 | ±40 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 16 PB50 | 16 | ±40 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
 AN3V 16 PB50
|
||||||||||
| AN3V 16 PB51 | 16 | ±40 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 180 PB35 | 180 | ±375 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 180 PB55 | 180 | ±375 | 5 | 2.5±2V | +1.0 | 250 | -40~105 | NA | + | |
| AN3V 20 PB30 | 20 | ±50 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 20 PB31 | 20 | ±50 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 20 PB50 | 20 | ±50 | 5 | 2.5±2V | ±1 | 250 | -40~105 | NA | + | |
 AN3V 20 PB50
|
||||||||||
| AN3V 20 PB51 | 20 | ±50 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 200 PB35 | 200 | ±375 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 200 PB55 | 200 | ±375 | 5 | 2.5±2V | +1.0 | 250 | -40~105 | NA | + | |
| AN3V 32 PB30 | 32 | ±80 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 32 PB31 | 32 | ±80 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 32 PB50 | 32 | ±80 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
 AN3V 32 PB50
|
||||||||||
| AN3V 32 PB51 | 32 | ±80 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 40 PB30 | 40 | ±100 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 40 PB31 | 40 | ±100 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 40 PB50 | 40 | ±100 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
 AN3V 40 PB50
|
||||||||||
| AN3V 40 PB51 | 40 | ±100 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 50 PB30 | 50 | ±125 | 3.3 | 1.65±1.15V | +1.0 | 250 | -40~150 | NA | + | |
 AN3V 50 PB30
|
||||||||||
| AN3V 50 PB31 | 50 | ±125 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 50 PB50 | 50 | ±125 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
 AN3V 50 PB50
|
||||||||||
| AN3V 50 PB51 | 50 | ±125 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 80 PB31 | 80 | ±200 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 80 PB35 | 80 | ±200 | 3.3 | 1.65±1.15V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 80 PB51 | 80 | ±200 | 5 | 2.5±2V | ±1.0 | 250 | -40~105 | NA | + | |
| AN3V 80 PB55 | 80 | ±200 | 5 | 2.5±2V | +1.0 | 250 | -40~105 | NA | + | |
 AN3V 80 PB55
|
||||||||||
| AN5V 10 PB00 | 10 | ±30 | ±12...15 | ±4V | ±1.0 | 50 | -40~85 | NA | + | |
 AN5V 10 PB00
|
||||||||||
| AN5V 15 PB00 | 15 | ±45 | ±12...15 | ±4V | ±1.0 | 50 | -40~85 | NA | + | |
 AN5V 15 PB00
|
||||||||||
| AN5V 20 PB00 | 20 | ±60 | ±12...15 | ±4V | ±1.0 | 50 | -40~85 | NA | + | |
 AN5V 20 PB00
|
||||||||||
| AN5V 25 PB00 | 25 | ±75 | ±12...15 | ±4V | ±1 | 50 | -40~85 | NA | + | |
 AN5V 25 PB00
|
||||||||||
| AN5V 30 PB00 | 30 | ±90 | ±12...15 | ±4V | ±1.0 | 50 | -40~85 | NA | + | |
 AN5V 30 PB00
|
||||||||||
| AN5V 50 PB00 | 50 | ±150 | ±12...15 | ±4V | ±1.0 | 50 | -40~85 | NA | + | |
 AN5V 50 PB00
|
||||||||||
| AN5V 60 PB00 | 60 | ±180 | ±12...15 | ±4V | ±1 | 50 | -40~85 | NA | + | |
 AN5V 60 PB00
|
||||||||||
| AR1A 100 H00 | 100 | ±100 | ±12...15 | ±20mA | ±1.0 | 5 | -40~85 | Ø20.0 | JK2EDG-5.08-4P | |
| AR1A 100 H01 | 100 | ±100 | ±12...15 | ±100mA | ±1.0 | 5 | -40~85 | Ø20.0 | JK2EDG-5.08-4P | |
| AR1A 200 H00 | 200 | ±200 | ±12...15 | ±20mA | ±1.0 | 5 | -40~85 | Ø20.0 | JK2EDG-5.08-4P | |
| AR1A 200 H01 | 200 | ±200 | ±12...15 | ±100mA | ±1.0 | 5 | -40~85 | Ø20 | JK2EDG-5.08-4P | |
| AR1A 50 H00 | 50 | ±50 | ±12...15 | ±20mA | ±1.0 | 5 | -40~85 | Ø20.0 | JK2EDG-5.08-4P | |
| AR1A 50 H01 | 50 | ±50 | ±12...15 | ±100mA | ±1.0 | 5 | -40~85 | Ø20 | JK2EDG-5.08-4P | |
| AS1V 100 H00 | 100 | ±100A | 5 | 2.5±2 | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 100 H01 | 100 | ±300 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 100 H07 | 100 | ±100 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | RVVP 3 x 0.3mmx 0.3mm -600 | |
| AS1V 200 H00 | 200 | ±200 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5x10.5 mm | Molex 5045-04A | |
| AS1V 200 H01 | 200 | ±600 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5x10.5 mm | Molex 5045-04A | |
| AS1V 200 H07 | 200 | ±200 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5x10.5 mm | RVVP 3 x 0.3mm x 0.3mm -600 | |
| AS1V 30 H05 | 30 | ±30 | 5 | 2.5±0.625V | +1 | 50 | -40~105 | 20.5x10.5 mm | RVVP 3×0.3mm×0.3mm-1000 | |
 AS1V 30 H05
|
||||||||||
| AS1V 300 H00 | 300 | ±300 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 300 H01 | 300 | ±900 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 400 H00 | 400 | ±400 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 400 H01 | 400 | ±900 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 50 H00 | 50 | ±50 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5x10.5 mm | MOLEX 5045-04A | |
 AS1V 50 H00
|
||||||||||
| AS1V 50 H01 | 50 | ±150 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5x10.5 mm | MOLEX 5045-04A | |
 AS1V 50 H01
|
||||||||||
| AS1V 500 H00 | 500 | ±500 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 500 H01 | 500 | ±900 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 600 H00 | 600 | ±600 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 600 H01 | 600 | ±900 | 5 | 2.5±0.625V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 700 H00 | 700 | ±700 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AS1V 800 H00 | 800 | ±800 | 5 | 2.5±2V | ±1.0 | 50 | -40~105 | 20.5 x 10.5 mm | MOLEX 5045-04A | |
| AT4V 100 H00 | 100 | ±300 | ±12...15 | ±4V | ±1.0 | 50 | -40~105 | 10 x 12mm（Three holes） | HX PZ2.54-1X6P WZ | |
 AT4V 100 H00
|
||||||||||
| AT4V 150 H00 | 150 | ±450 | ±12...15 | ±4V | ±1.0 | 50 | -40~105 | 10 x 12mm（Three holes） | HX PZ2.54-1X6P WZ | |
 AT4V 150 H00
|
||||||||||
| AT4V 200 H00 | 200 | ±600 | ±12...15 | ±4V | ±1.0 | 50 | -40~105 | 10 x 12mm（Three holes） | HX PZ2.54-1X6P WZ | |
 AT4V 200 H00
|
||||||||||
| AT4V 50 H00 | 50 | ±150 | ±12...15 | ±4V | ±1.0 | 50 | -40~105 | 10 x 12mm（Three holes） | HX PZ2.54-1X6P WZ | |
 AT4V 50 H00
|
||||||||||
| AT4V 75 H00 | 75 | ±225 | ±12...15 | ±4V | ±1.0 | 50 | -40~105 | 10 x 12mm（Three holes） | HX PZ2.54-1X6P WZ | |
 AT4V 75 H00
|
||||||||||
