ASIC sensors are known for their low sensitivity error and offset, making them reliable for various applications.
These sensors are advantageous due to their compact design and ability to provide precise current measurements without the need for additional insulation.
| Primary nominal RMS current (A) | 25 |
|---|---|
| Measuring range (A) | ±75 |
| Supply voltage (V) | ±12...15 |
| Secondary output | ±4V |
| Accuracy (%) | ±1 |
| Output bandwidth | 50 |
| Operating temperature (°C) | -40~85 |
| Copper busbar (mm) | NA |
| PCB | + |
| Others |
