These measure the strength of the magnetic field using a Hall element, producing a proportional voltage. They can measure both AC and DC currents and are common in automotive and industrial applications
| Primary nominal RMS current (A) | 10 |
|---|---|
| Measuring range (A) | ±30 |
| Supply voltage (V) | ±12...15 |
| Secondary output | ±4V |
| Accuracy (%) | ±1.0 |
| Output bandwidth | 50 |
| Operating temperature (°C) | -40~85 |
| Copper busbar (mm) | NA |
| PCB | + |
| Others |
